RSP-ZX
Anti-glare recessed spotlights with deep reflector design, UGR<17.5 options for comfortable office and retail lighting.
8 models in this series
FC-RSP-ZX-1
| Power | 3W |
| Cut-out Size | Φ35mm |
| Outer Diameter | Φ38mm |
| Height | H52mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-2
| Power | 5W |
| Cut-out Size | Φ35mm |
| Outer Diameter | Φ38mm |
| Height | H80mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-3
| Power | 5W |
| Cut-out Size | Φ40mm |
| Outer Diameter | Φ45mm |
| Height | H55mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-4
| Power | 8W |
| Cut-out Size | Φ40mm |
| Outer Diameter | Φ45mm |
| Height | H85mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-5
| Power | 7W |
| Cut-out Size | Φ50mm |
| Outer Diameter | Φ55mm |
| Height | H63mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-6
| Power | 10W |
| Cut-out Size | Φ50mm |
| Outer Diameter | Φ55mm |
| Height | H90mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-7
| Power | 8W |
| Cut-out Size | Φ60mm |
| Outer Diameter | Φ65mm |
| Height | H61mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
FC-RSP-ZX-8
| Power | 12W |
| Cut-out Size | Φ60mm |
| Outer Diameter | Φ65mm |
| Height | H98mm |
| CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
| CRI | 90 |
| UGR | <17.5 |
| IP Rating | IP44 |
| Beam Angle | 15°/24°/36°/45°/55° |
| Dimming / Control | DT6+DT8 / SCR dimming |
Price on request. Contact us for a quotation.
